3-Position, 5.08 mm Pitch Header with Board Lock
The mated stacking height range is 31.00 mm to 32.50 mm, which sets the board-to-board spacing budget for mezzanine or parallel-PCB configurations.
Mating and Stack Height Fit
The header mates with Dynamic D-3200 series receptacles (cable or board-mount) that accept tab contacts. The detent lock provides audible positive retention — useful in vibration-prone industrial panels. The 31.00 mm to 32.50 mm mated stack height range means the board-to-board spacing can be tuned within that window by selecting the appropriate receptacle stacking height.
