TE Connectivity AMP Connectors 1241050-2 — Pin Headers

1241050-2 TE AMPMODU Mod II 4-Pin SMT Header – Active

MPN1241050-2
Active

TE Connectivity AMP Connectors AMPMODU Mod II, 4-position, 2.54mm pitch, unshrouded breakaway header, SMT, gold flash male pins, active production.

$1.7708Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 1241050-2 datasheet (PDF)
RoHSROHS3 Compliant
SeriesAMPMODU Mod II
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

1241050-2 key specifications
ParameterValue
SeriesAMPMODU Mod II
TypeMale Pin
MountingSurface Mount
Connector typeHeader, Breakaway
Fastening typePush-Pull
Contact materialBrass
Insulation colorBlack
Insulation height0.110\" (2.79mm)
Insulation materialPolycyclohexylenedimethylene Terephthalate (PCT)
StyleBoard to Board or Cable
PackageTape & Reel (TR); Cut Tape (CT)
FeaturesPick and Place

All specifications

1241050-2 additional specifications
ParameterValue
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions4
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact finish - matingGold or Gold-Palladium
Contact length - mating0.228\" (5.80mm)
Contact finish thickness - post118.1µin (3.00µm)
Contact finish thickness - matingFlash

Product details

4-Pin Breakaway in the AMPMODU Mod II Family

The 1241050-2: The square male pins carry a gold or gold-palladium flash on the mating surface, keeping contact resistance low for occasional unmate cycles.

SMT Assembly and Pick-and-Place Ready

The header is surface-mount terminated and ships on tape and reel, with a pick-and-place feature that allows automated placement during reflow.

Confirm availability and current pricing at quote time.

Peer Comparison: 1394090-1

Peer 1394090-1 is a 6-position, single-row, shrouded through-hole header with tin contacts — it is not a form-fit-function substitute for the 1241050-2.

Frequently asked questions

What mates with 1241050-2?

As an unshrouded breakaway header, it mates with any standard 2.54mm-pitch receptacle that accepts 0.64mm square pins — typically AMPMODU Mod II or compatible IDC sockets. The mating contact length is 5.80mm.

Where can I buy 1241050-2 available via RFQ confirmation?

Sourced to order against your BOM quantity. Availability and current pricing confirmed at quote time.
