TE Connectivity AMP Connectors.025 series, 1473143-1, 2-position plug housing, 2.20mm pitch, female socket contacts, locking ramp, free-hanging, black PBT, -30°C to 100°C, contacts not included.
| Parameter | Value |
|---|---|
| Series | .025 |
| Type | Female Socket |
| Mounting | Free Hanging (In-Line) |
| Connector type | Plug |
| Fastening type | Locking Ramp |
| Operating temperature | -30°C ~ 100°C |
| Color | Black |
| Insulation material | Polybutylene Terephthalate (PBT), Glass Filled |
| Note | Contacts Not Included |
| Pitch | 0.087\" (2.20mm) |
| Package | Bulk |
| Rows | 1 |
| Contact termination | Crimp |
| Positions | 2 |
The 1473143-1: The 2.20 mm pitch (0.087") is a common spacing for signal-level interconnects, giving enough room for 20-24 AWG wire without crowding the board footprint.
This is a single-row, 2-position housing — a common configuration for power-in or sensor connections where only two wires are needed.
No — the 1473143-1 is a plug housing only.
The pitch is 0.087" (2.20 mm), a standard spacing for this class of wire-to-board connector.
Yes, it is ROHS3 compliant, meeting the latest EU directive requirements.
