Stacked terminal gender
The 160739-2 is a Faston-series stacked terminal combining female receptacle and male tab in one body — both genders are listed on the same part, so a single crimp operation produces a mated pair ready for in-line splicing. It accepts 14-18 AWG wire and terminates with a standard crimp tool; the tin-plated brass contact carries the current through the stacked interface without a separate housing.
Tab dimensions and wire range
Tab width is 0.250" (6.35mm) with a tab thickness of 0.032" (0.81mm) and tab length of 0.303" (7.70mm) — these dimensions match standard 0.250" quick-disconnect receptacles. Overall length is 0.791" (20.09mm). The insulation diameter range is 0.118" to 0.169" (3.00mm to 4.29mm), which covers the jacket OD of common 14-18 AWG primary wire.
