TE Connectivity AMP Connectors EI series header, 176153-6, 6-position single-row, 2.50 mm pitch, right-angle through-hole, shrouded with latch holder, male pin, solder termination, natural PA66 housing, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | EI |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Voltage rating | 250VAC, 350VDC |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -20°C~85°C |
| Contact material | Brass |
| Insulation color | Natural |
| Insulation height | 0.264\" (6.70mm) |
| Insulation material | Polyamide (PA66), Nylon 6/6 |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Bulk |
| Shrouding | Shrouded - 1 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.098\" (2.50mm) |
| Positions | 6 |
| Contact length - post | 0.142\" (3.60mm) |
| Contact length - mating | 0.295\" (7.49mm) |
The 1-292164-1 is an 11-position, 2.00 mm pitch header from the CT series — tighter pitch and more circuits, but the 176153-6's 2.50 mm pitch gives more room for routing and a slightly higher current ceiling per contact. The 176153-6 uses a latch holder; the 1-292164-1 uses a detent lock, which is a different retention feel.
The 176153-6 is sourced through independent distribution against an RFQ.
The mating pitch is 0.098" (2.50 mm). This is the centre-to-centre spacing between adjacent pins.
Yes, it is listed as RoHS Compliant.
The part has 6 positions, all loaded, in a single row. The pinout is a straight 1-to-6 sequence; no keying or polarisation is specified beyond the single-wall shroud.
Yes, it has a single-wall shroud on the mating face, which protects the male pins during connection.
