TE Connectivity AMP Connectors 207015-1 — Connector Housings

TE Metrimate 207015-1 Plug Housing, 4 Pos, 5.00mm

MPN207015-1
Active

TE Connectivity Metrimate plug housing, 207015-1, 4 positions, 5.00mm pitch, 2 rows, free-hanging, locking ramp, crimp and solder termination, black thermoplastic, -55°C to 130°C.

$1.7900Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesMetrimate
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

207015-1 specifications
ParameterValue
SeriesMetrimate
TypeFemale Socket
MountingFree Hanging (In-Line)
Connector typePlug
Fastening typeLocking Ramp
Operating temperature-55°C ~ 130°C
ColorBlack
Insulation materialThermoplastic
NoteContacts Not Included
Pitch0.197\" (5.00mm)
PackageBulk
Row spacing0.197\" (5.00mm)
Rows2
Contact terminationCrimp and Solder
Positions4

Product details

What this Metrimate plug housing is for

The locking ramp on the plug body clicks into the matching receptacle and stays put; you hear the latch seat, which is the field check that the pair won't back out.

The note on the line says it: contacts are not included. This is a housing only — you order the 207015-1 shell and then separately source the female crimp terminals that go into it.

Mating and termination fit

This is a free-hanging (in-line) plug, so it mates with a panel-mount or in-line receptacle from the same Metrimate series.

Sourcing this housing

The 207015-1 is listed as Active on the lifecycle record, so it's still in the TE catalog. The black thermoplastic housing ships in bulk packaging.

Frequently asked questions

What contacts are compatible with 207015-1?

Buyers need to know the correct mating contacts to complete the connector assembly.

Is 207015-1 in stock at major distributors?

Sourcing buyers need immediate availability to avoid delays in production.

What is the price of 207015-1?

Pricing directly impacts BOM cost and budget approval for procurement.

What is the replacement or equivalent for 207015-1?

Engineers or buyers need drop-in alternatives when the exact part is unavailable or obsolete.

Where can I buy 207015-1 in bulk?

Volume purchasers look for best pricing and lead times on larger quantities.

What is the datasheet for 207015-1?

Design engineers need full electrical and mechanical specs to validate fit in their application.
