TE Connectivity Metrimate receptacle housing, 207016-1, 4 positions, 2 rows, 5.00mm pitch, free hanging in-line, latch lock, black thermoplastic, -55°C to 130°C.
| Parameter | Value |
|---|---|
| Series | Metrimate |
| Type | Male Pin |
| Mounting | Free Hanging (In-Line) |
| Connector type | Receptacle |
| Fastening type | Latch Lock |
| Operating temperature | -55°C ~ 130°C |
| Color | Black |
| Insulation material | Thermoplastic |
| Note | Contacts Not Included |
| Pitch | 0.197\" (5.00mm) |
| Package | Bulk |
| Row spacing | 0.197\" (5.00mm) |
| Rows | 2 |
| Contact termination | Crimp and Solder |
| Positions | 4 |
The housing accepts crimp and solder termination, but the standard field-termination method is crimp, using the TE application tooling for consistent pull-force. Don't order half a connection: pair this receptacle with the correct pin contacts and the mating plug header to complete the harness.
No obsolescence notice or last-time-buy window is in effect.
No, the 207016-1 is a receptacle housing only — contacts are not included. You must order the matching male pin crimp terminals separately to complete the connection.
The 207016-1 has a 0.197" (5.00 mm) pitch with the same 5.00 mm row spacing, giving a 2x2 grid for the four positions.
The 207016-1 receptacle mates with the corresponding Metrimate plug header (male pin side) at the same 5.00 mm pitch. The latch lock secures the mated pair.
