TE Connectivity AMP Connectors 207017-1 — Connector Housings

TE Metrimate 207017-1 Plug Housing, 12 Pos, 5.00mm

MPN207017-1
Active

TE Metrimate series, plug housing, 207017-1, 12 positions, 5.00mm pitch, 3 rows, locking ramp, free hanging, black thermoplastic, ROHS3 compliant.

$4.2300Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 207017-1 datasheet (PDF)
RoHSROHS3 Compliant
SeriesMetrimate
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

207017-1 specifications
ParameterValue
SeriesMetrimate
TypeFemale Socket
MountingFree Hanging (In-Line)
Connector typePlug
Fastening typeLocking Ramp
Operating temperature-55°C ~ 130°C
ColorBlack
Insulation materialThermoplastic
NoteContacts Not Included
Pitch0.197\" (5.00mm)
PackageBulk
Row spacing0.197\" (5.00mm)
Rows3
Contact terminationCrimp and Solder
Positions12

Product details

The TE Metrimate 207017-1 is a 12-position plug housing in the Metrimate series, built on a 5.00 mm pitch in a 3-row layout.

Operating temperature from -55°C to 130°C covers engine-bay heat and cold-soak in outdoor gear.

What's Not in the Bag — Contacts Sold Separately

This is a bare housing — you order the 207017-1 for the shell and the locking ramp, then source the matching female crimp terminals (Metrimate series, 20-14 AWG range typically) separately. If you're building a harness from scratch, add the terminal part number to your BOM line now; if you're replacing a damaged housing on an existing harness, you can re-pin it on site with a standard crimp tool as long as the old terminals are still good.

Field-repairable: a bad terminal gets pulled and re-crimped without scrapping the whole harness.

Frequently asked questions

Does 207017-1 include contacts?

No. The 207017-1 is a bare plug housing — contacts are not included. You need to order the matching Metrimate female crimp terminals separately for your wire gauge.

What is the mating connector for 207017-1?

It mates with a Metrimate series male pin header that has the same 5.00 mm pitch and 3-row layout. Look for a Metrimate header with a locking ramp catch on the sides.

Is 207017-1 RoHS compliant?

Yes, it is ROHS3 compliant.
