Pitch and current rating for the BOM line
The 207119-8 is a 4-position, dual-row header on a 4.98 mm pitch, rated 7.5 A per circuit at 600 V — the pitch and current together set the board footprint and the power budget for a single connector.
207119-8 TE Metrimate Header 4 Pos 4.98mm Pitch
MPN207119-8
Active
TE Connectivity Metrimate 207119-8, dual-row 4-position 4.98 mm pitch header, rated 7.5 A per circuit at 600 V, through-hole vertical with tin-plated brass contacts, latch-lock four-wall shroud, mounting flange, polyamide insulator rated -55 to 130 °C.
$9.4400Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesMetrimate
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Metrimate |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Latch Lock |
| Voltage rating | 600V |
| Current rating | 7.5A |
| Operating temperature | -55°C ~ 130°C |
| Contact material | Brass |
| Insulation color | Black, Red |
| Insulation height | 0.464\" (11.79mm) |
| Insulation material | Polyamide (PA), Nylon |
All specifications
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Bulk |
| Features | Mounting Flange |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Industrial |
| Contact shape | Circular |
| Rows | 2 |
| Pitch | 0.196\" (4.98mm) |
| Positions | 4 |
| Row spacing - mating | 0.196\" (4.98mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.181\" (4.60mm) |
| Contact finish - mating | Tin |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 150.0µin (3.81µm) |
Product details
Frequently asked questions
What housing mates with 207119-8?
The 207119-8 is a header with male pins; it mates with a Metrimate receptacle housing that accepts the corresponding crimp terminals. The latch-lock shroud engages the receptacle's locking ramp — confirm the receptacle part number from the Metrimate series for your wire gauge and circuit count.
What is the difference between 207119-8 and 207119-4?
The base product number 207119 covers multiple position counts. The 207119-8 is a 4-position header; the 207119-4 would be a different position count within the same series — confirm the exact circuit count on your BOM before substituting.
