TE Connectivity Metrimate series plug housing, 207152-1, 6 positions, 2 rows, 5.00 mm pitch, free-hanging, locking ramp, black thermoplastic, crimp termination, contacts not included.
| Parameter | Value |
|---|---|
| Series | Metrimate |
| Type | Female Socket |
| Mounting | Free Hanging (In-Line) |
| Connector type | Plug |
| Fastening type | Locking Ramp |
| Operating temperature | -55°C ~ 130°C |
| Color | Black |
| Insulation material | Thermoplastic |
| Note | Contacts Not Included |
| Pitch | 0.197\" (5.00mm) |
| Package | Bulk |
| Row spacing | 0.197\" (5.00mm) |
| Rows | 2 |
| Contact termination | Crimp and Solder |
| Positions | 6 |
The 2-row layout with 0.197" (5.00 mm) row spacing keeps the housing compact while allowing the crimp terminals to seat fully.
The 207152-1 carries 6 positions, while the sibling 207015-1 carries 4 positions at the same 5.00 mm pitch and 2-row layout. Both use the same locking ramp and accept the same crimp socket terminals.
No, the 207152-1 is a housing only. The listing explicitly notes 'Contacts Not Included'. You must order the matching crimp socket terminals separately for the Metrimate series.
The 207152-1 is a plug housing that mates with the corresponding Metrimate series header. The mating half is a pin header with 6 positions on the same 5.00 mm pitch and 2-row layout.
