TE Connectivity AMP Connectors Metrimate series, 207359-1, receptacle housing, 3 positions, 0.197" (5.00mm) pitch, single row, latch lock, free hanging, black or red thermoplastic, contacts not included.
| Parameter | Value |
|---|---|
| Series | Metrimate |
| Type | Male Pin |
| Mounting | Free Hanging (In-Line) |
| Connector type | Receptacle |
| Fastening type | Latch Lock |
| Operating temperature | -55°C ~ 130°C |
| Color | Black or Red |
| Insulation material | Thermoplastic |
| Note | Contacts Not Included |
| Pitch | 0.197\" (5.00mm) |
| Package | Bulk |
| Rows | 1 |
| Contact termination | Crimp and Solder |
| Positions | 3 |
The 207359-1: For a complete mated assembly, pair this receptacle housing with the corresponding Metrimate plug housing and the correct male pin crimp terminals (TE part numbers for the terminals are listed in the series drawing).
The 6-position sibling 207376-1 shares the same pitch, latch lock, and contact type, differing only in circuit count.
No.
It mates with a Metrimate series plug housing that accepts female pin contacts. The exact plug MPN depends on the position count and keying; confirm against the series drawing.
Yes, it is ROHS3 Compliant.
0.197" (5.00mm).
