TE Connectivity AMP Connectors Metrimate series, 207439-1, plug housing, 9 positions, 5.00mm pitch, 3 rows, free-hanging, locking ramp, black thermoplastic, contacts not included.
| Parameter | Value |
|---|---|
| Series | Metrimate |
| Type | Female Socket |
| Mounting | Free Hanging (In-Line) |
| Connector type | Plug |
| Fastening type | Locking Ramp |
| Operating temperature | -55°C ~ 130°C |
| Color | Black |
| Insulation material | Thermoplastic |
| Note | Contacts Not Included |
| Pitch | 0.197\" (5.00mm) |
| Package | Bulk |
| Row spacing | 0.197\" (5.00mm) |
| Rows | 3 |
| Contact termination | Crimp and Solder |
| Positions | 9 |
This is the 207439-1, a 9-position plug housing from TE's Metrimate series. The black thermoplastic body handles -55°C to 130°C, and contacts are ordered separately.
The 5.00mm pitch and 3-row layout set this apart from the 2-row, 2.00mm pitch 1-2333134-5 receptacle. If your design calls for a 30-position receptacle at tighter pitch, that's the alternative; for a 9-position plug, this is the one.
The housing accepts crimp and solder termination.
It mates with a corresponding receptacle housing loaded with male pins.
