TE Connectivity Metrimate receptacle housing, 207440-1, 9 positions, 3 rows, 5.00mm pitch, free-hanging, latch lock, black thermoplastic, -55°C to 130°C.
| Parameter | Value |
|---|---|
| Series | Metrimate |
| Type | Male Pin |
| Mounting | Free Hanging (In-Line) |
| Connector type | Receptacle |
| Fastening type | Latch Lock |
| Operating temperature | -55°C ~ 130°C |
| Color | Black |
| Insulation material | Thermoplastic |
| Note | Contacts Not Included |
| Pitch | 0.197\" (5.00mm) |
| Package | Bulk |
| Row spacing | 0.197\" (5.00mm) |
| Rows | 3 |
| Contact termination | Crimp and Solder |
| Positions | 9 |
The TE Connectivity Metrimate 207440-1 is a 9-position receptacle housing from the Metrimate series, built on a 5.00 mm pitch with three rows. It is a free-hanging (in-line) housing designed for crimp-and-solder pin contacts — the contacts themselves are ordered separately.
Contacts are not included with this housing — order male pin contacts separately and crimp or solder them onto the wire.
The 207440-1 accepts standard Metrimate male pin crimp contacts, such as TE part numbers 1-66361-0 and 1-66361-1. Contacts are ordered separately.
Yes, the 207440-1 is ROHS3 compliant.
