10.7 A Shielded DC Power Jack for Cable Assemblies
It carries 3 conductors across 5 contacts, rated at 10.7 A and 25 VDC, making it suited for the DC input rail of portable equipment, monitors, or similar devices where a shielded power path is needed. The shielded construction contains EMI from the switching supply side, while the solder eyelet termination allows field-termination or pigtail assembly without a PCB footprint.
Contact Arrangement and Termination Style
The 3-conductor, 5-contact arrangement means the jack has separate power and ground paths plus an additional sense or coaxial center contact — typical for a coaxial power barrel where the center pin carries the rail and the outer shell returns ground. The solder eyelet termination accepts stripped wire ends or tinned leads; the eyelets are large enough for hand-soldering in a harness build.
