Locking ramp keeps the mate secure under vibration
In a sealed connector system, that latch is what prevents the pair from backing off under engine vibration or equipment jolts — no secondary lock needed for most harness runs.
TE Superseal 282106-2 Receptacle Housing, 4 Pos, 6.00mm
MPN282106-2
Active
TE Connectivity Superseal receptacle housing, 282106-2, 4 positions, 6.00mm pitch, 1 row, gray, locking ramp, free hanging, crimp termination, -40°C to 125°C.
$0.8600Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesSuperseal
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Superseal |
| Type | Tab |
| Mounting | Free Hanging (In-Line) |
| Connector type | Receptacle |
| Fastening type | Locking Ramp |
| Operating temperature | -40°C ~ 125°C |
| Color | Gray |
| Insulation material | Polyamide (PA66), Nylon 6/6, Glass Filled |
| Note | Contacts Not Included |
| Pitch | 0.236\" (6.00mm) |
| Package | Bulk |
| Rows | 1 |
| Contact termination | Crimp |
| Positions | 4 |
Product details
Frequently asked questions
Does 282106-2 include contacts?
No — the housing ships without contacts. The note Contacts Not Included is listed on the spec line. You must order the matching Superseal crimp tab terminals separately.
What contacts are compatible with 282106-2 housing?
The housing accepts Superseal tab contacts with crimp termination. The 6.00 mm pitch and single-row layout are standard for the series; confirm the wire gauge and terminal part number from the Superseal terminal datasheet before ordering.
Where can I buy TE 282106-2 Superseal receptacle housing?
This part is sourced to order through independent distribution. Submit an RFQ for current pricing and lead time confirmation.
