TE Connectivity AMP Connectors Micro MATE-N-LOK socket housing, 293735-1, 4 circuits, 0.118" (3.00 mm) pitch, dual-row, black, free-hanging, latch holder, contacts not included, bulk package.
| Parameter | Value |
|---|---|
| Series | Micro MATE-N-LOK |
| Type | Male Pin |
| Mounting | Free Hanging (In-Line) |
| Connector type | Socket |
| Fastening type | Latch Holder |
| Operating temperature | -20°C ~ 85°C |
| Color | Black |
| Insulation material | Polyamide (PA), Nylon |
| Note | Contacts Not Included |
| Pitch | 0.118\" (3.00mm) |
| Package | Bulk |
| Features | Cover |
| Row spacing | 0.118\" (3.00mm) |
| Rows | 2 |
| Contact termination | Crimp |
| Positions | 4 |
The 293735-1: It accepts male pin contacts terminated via crimp, making it the wire-side receptacle half of a Micro MATE-N-LOK pair.
Dual-row layout at 0.118" (3.00 mm) pitch with matching row spacing, 4 positions total — mates with a 4-circuit male header (pin housing) of the same series.
No — contacts are not included. The housing accepts separately ordered male pin crimp terminals.
0.118" (3.00 mm) pitch, dual rows with matching 0.118" row spacing.
