TE Connectivity AMPMODU System 50, FFC receptacle housing, 7 positions, 0.050" (1.27mm) pitch, 1.5 A, 100 V, UL94 V-0, black polyester, detent lock, contacts not included.
| Parameter | Value |
|---|---|
| Series | AMPMODU System 50 |
| Connector type | Housing for Female Contacts |
| Flat flex type | FFC |
| Voltage rating | 100 V |
| Current rating | 1.5 A |
| Operating temperature | -55°C ~ 105°C |
| Housing color | Black |
| Housing material | Polyester |
| Material flammability rating | UL94 V-0 |
| Note | Contacts Not Included |
| Pitch | 0.050\" (1.27mm) |
| Package | Bulk |
| Rows | 1 |
| Locking feature | Detent Lock |
| FFC, FCB thickness | 0.05-0.08mm |
| Positions | 7 |
The 487544-4: This is the AMPMODU System 50 receptacle housing for 0.050" (1.27mm) pitch FFC cable, 7 circuits in a single row. The housing accepts FFC thickness 0.05-0.08mm — match the cable thickness to the actuator clearance or the flex won't seat fully.
The listing note states Contacts Not Included. The housing ships empty — you need the matching AMPMODU System 50 crimp terminal for the FFC cable.
487544-4 is sourced to order through our distribution network. Submit an RFQ for current availability and pricing — confirmed at quote time.
The housing ships empty; you must order the matching AMPMODU System 50 crimp terminal separately.
0.050" (1.27mm) pitch, single row, 7 positions. This is the standard AMPMODU System 50 fine-pitch spacing for FFC interconnects.
Yes — listed as ROHS3 Compliant.
