Panel-Mount BNC HD for 50 Ohm RF Paths
The 034-5023: It mounts through a bulkhead panel with the included front-side nut and terminates to the PCB via through-hole solder on both the shield and centre contact.
The 500-cycle rating, supported by the gold-over-beryllium copper centre contact, means it survives repeated field mating in test setups or portable gear without the centre pin wearing into a high-resistance contact. The nickel body finish resists corrosion in humid or outdoor environments where a bare brass shell would tarnish and degrade the shield continuity.
Panel mount with a bulkhead hole sized for the front-side nut — the connector ships with the nut included, so no separate hardware order. The through-hole tails require the board to have plated holes matching the pin diameter. The bayonet lock mates with a standard BNC HD plug — the keying is the same as standard BNC, so a standard BNC plug will not mate correctly with this HD variant.
