Amphenol ICC (FCI) BERGSTIK II header, breakaway, order code 10119109-530022LF, 30 positions, dual row, 0.100" (2.54mm) pitch, gold-plated mating contacts, through-hole, solder termination.
Amphenol BERGSTIK II 10119109-530022LF Header, 30-Pos 0.100"
MPN10119109-530022LF
Active
Amphenol ICC (FCI) BERGSTIK II header, breakaway, order code 10119109-530022LF, 30 positions, dual row, 0.100" (2.54mm) pitch, gold-plated mating contacts, through-hole, solder termination.
$3.6689Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bag |
| Shrouding | Unshrouded |
All specifications
| Parameter | Value |
|---|---|
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 30 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.120\" (3.05mm) |
| Overall contact length | 0.450\" (11.43mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
What is the board-to-board style of this header?
The 10119109-530022LF is listed as a Board to Board style header, unshrouded, with push-pull fastening.
