65801-003LF — Amphenol product photo
Amphenol

65801-003LF FFC/FPC Receptacle, 3 Pos, 2.54mm, ZIF, Tin

MPN65801-003LF
Active

Amphenol ICC (FCI) Clincher™ 65801-003LF, 3-position FFC/FPC receptacle, 0.100" (2.54mm) pitch, ZIF slide lock, tin-plated contacts, 2 A, 500 V, free-hanging, UL94 V-0.

$1.1400Ref. price · indicative, final on quote
65801-003LF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

65801-003LF Technical Specifications
ParameterValue
SeriesClincher™
Mounting typeFree Hanging (In-Line)
Cable end typeStraight, Tapered
Flat flex typeFFC, FPC
Connector (Contact type)Receptacle
Voltage rating500V
Current rating2A
Operating temperature-65°C~105°C
Housing colorBlue
Actuator colorBlack
Contact materialCopper Nickel Alloy
Housing materialThermoplastic
Material flammability ratingUL94 V-0
Pitch0.100\" (2.54mm)
PackageTray
FeaturesSolder Retention, Zero Insertion Force (ZIF)
TerminationSolder
Mating cycles100
Contact finishTin
Locking featureSlide Lock
FFC, FCB thickness0.30mm, 0.33mm
Positions3
Contact finish thickness100.0µin (2.54µm)

Product details

The 65801-003LF: With 3 positions, this is a compact signal or low-power interconnect for a single flex tail.

Current, Voltage, and Plating — What the Ratings Carry

The thick tin layer handles moderate-cycle duty (100 mating cycles) without fretting corrosion — suitable for test points, programming headers, or low-power sensor connections where the flex is mated and unmated occasionally.

Flex Cable Compatibility — Thickness and Termination

Accepts FFC or FPC cable 0.30mm or 0.33mm thick, with straight or tapered cable end types.

Frequently asked questions

What is the closest alternative to 65801-003LF?

The 65801-004LF is the 4-position version of the same Clincher™ series. All ratings (pitch, current, voltage, plating, thickness range) are identical; only the position count changes. If you need more circuits, the 8-position (65801-008LF) and 9-position (65801-009LF) are also direct siblings.

What FFC/FPC thickness does 65801-003LF accept?

It accepts 0.30mm or 0.33mm thick FFC or FPC cable, with straight or tapered cable end types. The ZIF slide lock clamps the cable without force.
