78207-110HLF — Amphenol product photo
Amphenol

78207-110HLF Pin Header – Amphenol ICC (FCI) 10-Pos 2.54mm

MPN78207-110HLF
Active

Amphenol ICC (FCI) Mini-PV™, Basics+ series, 10-position, 2-row, 0.100" (2.54mm) pitch, right-angle through-hole header, shrouded 2-wall, friction lock, male pin, square contact, phosphor bronze, gold or GXT™ 30.0µin mating finish, black UL94 V-0 insulator, bulk.

$1.0600Ref. price · indicative, final on quote
78207-110HLF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

78207-110HLF Technical Specifications
ParameterValue
SeriesMini-PV™, Basics+
GenderMale Pin
Mounting typeThrough Hole, Right Angle
Connector typeHeader
Fastening typeFriction Lock
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.303\" (7.70mm)
Material flammability ratingUL94 V-0
StyleBoard to Cable/Wire
PackageBulk
FeaturesKeying Slot
ShroudingShrouded - 2 Wall
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions10
Row spacing - mating0.100\" (2.54mm)
Contact length - post0.120\" (3.05mm)
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

Right-Angle 10-Pin Header with Friction Lock

The 78207-110HLF: The keying slot prevents inserting the wrong mating half.

The black colour is consistent across the Mini-PV™ series, making visual inspection of populated boards straightforward.

The 78207-110HLF carries 10 positions. Siblings in the same 78207 base number include a 12-position variant (78207-112HLF) with identical pitch, plating, and locking — the only difference is the extra two circuits. If the BOM calls for 12 positions, the 78207-112HLF is a direct drop-in on the same 0.100" row spacing.

Frequently asked questions

Where can I buy 78207-110HLF?

78207-110HLF is available through independent distribution. Submit an RFQ for this part number.

What is the closest functional alternative to 78207-110HLF?

The 78207-110 (without the HLF suffix) is the same 10-position, right-angle, 0.100" pitch header with identical plating and locking. The HLF suffix typically indicates a lead-free finish — both are RoHS compliant. Either can be used as a second-source if the BOM allows the finish variation.
