901-10007 — Amphenol product photo
Amphenol

Amphenol 901-10007 SMA to 1.0/2.3 Adapter, 50 Ohm, 4 GHz

MPN901-10007
Active

Amphenol RF, SMA to 1.0/2.3 between-series adapter, 901-10007, straight, plug to plug, male to male, 50 Ohms, 4 GHz, free hanging, bulk.

$14.4100Ref. price · indicative, final on quote
901-10007 datasheet
StockContact for availability
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

901-10007 Technical Specifications
ParameterValue
Adapter typePlug to Plug
Mounting typeFree Hanging (In-Line)
Adapter seriesSMA to 1.0/2.3
Fastening typeSnap-On, Threaded
Conversion typeBetween Series
Frequency - max4 GHz
Operating temperature-40°C ~ 155°C
Body materialBeryllium Copper; Stainless Steel
Dielectric materialPolytetrafluoroethylene (PTFE)
Center contact materialBrass
StyleStraight
Impedance50 Ohms
PackageBulk
Body finishGold; Passivated
Center genderMale to Male
Center contact platingGold
Convert to (Adapter end)1.0/2.3 Plug, Male Pin
Convert from (Adapter end)SMA Plug, Male Pin

Product details

Between-Series Adapter: SMA Plug to 1.0/2.3 Plug

The Amphenol RF 901-10007 is a between-series adapter that converts from an SMA plug, male pin to a 1.0/2.3 plug, male pin. It is a straight, free-hanging (in-line) adapter with a 50 Ohm impedance, rated to 4 GHz maximum frequency. The SMA end uses a threaded fastening, while the 1.0/2.3 end uses a snap-on coupling, giving you two different retention methods on a single adapter body.

The adapter body is machined from beryllium copper and stainless steel with a gold and passivated finish. The dielectric is PTFE (polytetrafluoroethylene), the standard choice for RF applications requiring stable dielectric properties across temperature.

Frequency Rating and What It Means

The adapter is rated to 4 GHz maximum frequency.

Frequently asked questions

What is the difference between the 901-10007 and SMA to 1.0/2.3 adapters from other manufacturers?

The 901-10007 is an Amphenol RF part with a beryllium copper and stainless steel body, gold and passivated finish, and PTFE dielectric. Performance differences between manufacturers depend on interface geometry compliance and material quality, but the electrical specs (50 Ohm, 4 GHz) are standard for the interface type.
