DX07B024JJ3R1600
JAE Electronics
24USB 3.2 Gen 2 (USB 3.1 Gen 2, Superspeed + (USB 3.1))Receptacle
Ref. price$2.6200
Lead time on requestGet quote ›
JAE Electronics DX07 Series
28 variants · JAE Electronics
About the JAE Electronics DX07 Series
The JAE Electronics DX07 Series series groups 28 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common connector type of USB-C (USB TYPE-C), contact finish of Gold and insulation color of Black. Variants differ by current rating, features and gender, so you can match the exact current rating your application requires using the selection guide below. All listed JAE Electronics DX07 Series part numbers are active and orderable.
Select a variant by
- Current rating
- - · 0.25A, 1.25A · 0.25A, 1.25A, 5A, 6.25A · 5A
- Features
- - · Board Guide · Board Lock · Cover · Pick and Place
- Gender
- Plug · Receptacle
- Mounting feature
- Horizontal · Horizontal, Mid Mount · Reversible
- Mounting type
- Board Cutout, Surface Mount, Right Angle; Through Hole · Board Edge, Cutout; Surface Mount; Through Hole, Right Angle · Board Edge, Straddle Mount · Board Edge, Surface Mount, Right Angle · Surface Mount, Right Angle; Through Hole
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
- Positions
- 24 · 24 (22+2 Dummy)
- Voltage - rated
- 20V · 20VAC
Shared specifications
- Connector type
- USB-C (USB TYPE-C)
- Contact finish
- Gold
- Insulation color
- Black
- Mating cycles
- 10000
- Number of ports
- 1
- Operating temperature
- -30°C ~ 80°C
- Shell (Shielding material)
- Steel, Stainless
- Shielding
- Shielded
- Specifications
- USB 3.2 Gen 2 (USB 3.1 Gen 2, Superspeed + (USB 3.1))
- Termination
- Solder
Variant comparison
| Parameter | DX07B024JJ3R1600 | DX07BN24JA2R1300 | DX07P022AA6R2000 | DX07P024MJ1R1500 | DX07S024JA2R1200 | DX07S024JJ2R1300 |
|---|---|---|---|---|---|---|
| Current rating | 0.25A, 1.25A | 0.25A, 1.25A, 5A, 6.25A | - | 0.25A, 1.25A | 5A | 0.25A, 1.25A |
| Features | - | - | Cover | Cover | Board Lock | Pick and Place |
| Gender | Receptacle | Receptacle | Plug | Plug | Receptacle | Receptacle |
| Mounting feature | Horizontal, Mid Mount | Horizontal, Mid Mount | Reversible | Reversible | Horizontal | Horizontal |
| Mounting type | Board Cutout, Surface Mount, Right Angle; Through Hole | Board Edge, Cutout; Surface Mount; Through Hole, Right Angle | Board Edge, Straddle Mount | Board Edge, Straddle Mount | Surface Mount, Right Angle; Through Hole | Surface Mount, Right Angle; Through Hole |
| Package | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) |
| Positions | 24 | 24 | 24 (22+2 Dummy) | 24 | 24 | 24 |
| Voltage - rated | 20V | 20V | 20VAC | 20VAC | 20V | 20V |
