Major League Electronics — Pin Headers

Major League Electronics Pin Headers — 6 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.

Contact Length - Post
0.318" (8.08mm) · 0.475" (12.07mm) · 0.175" (4.45mm) · -
Number of Positions
40 · 24 · 4 · 8
Insulation Height
0.098" (2.50mm) · 0.125" (3.18mm) · 0.368" (9.35mm) · 0.100" (2.54mm)
Contact Length - Mating
0.230" (5.84mm) · 0.150" (3.81mm) · 0.320" (8.13mm) · 0.318" (8.08mm)
Overall Contact Length
- · 0.750" (19.05mm) · 0.335" (8.51mm) · 0.255" (6.48mm)
Pitch - Mating
0.100" (2.54mm) · 0.156" (3.96mm) · 0.200" (5.08mm) · 0.050" (1.27mm)
Contact Finish Thickness - Mating
10.0µin (0.25µm) · - · Flash · 3.00µin (0.076µm)
Current Rating (Amps)
3A · 7.9A · 1A · 2A
