Same Sky — Wire-to-Board Connectors

Same Sky Wire-to-Board Connectors — 22 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.

Base Product Number
PJ-008 · PJ-011 · PJ-014 · PJ-015
Actual Diameter
0.079" (2.00mm ID), 0.224" (5.70mm OD) · 0.098" (2.50mm ID), 0.236" (6.00mm OD) · 0.039" (1.00mm ID), 0.154" (3.90mm OD) · 0.079" (2.00mm ID), 0.260" (6.60mm OD)
Mating Length/Depth
0.354" (9.00mm) · - · 0.232" (5.90mm) · 0.374" (9.50mm)
Mounting Type
Panel Mount · Surface Mount, Right Angle · Surface Mount · Through Hole, Right Angle
Current Rating (Amps)
2.5 A · 5 A · 3.5 A · 2 A
Housing Material
Polybutylene Terephthalate (PBT) · Polyoxymethylene (POM) · Polyamide (PA6T), Nylon 6T · Polyamide (PA66), Nylon 6/6
Industry Recognized Mating Diameter
2.10mm ID (0.083"), 5.50mm OD (0.217") · 2.50mm ID (0.098"), 5.50mm OD (0.217") · 1.00mm ID (0.039"), 3.40mm OD (0.134") · 1.00mm ID (0.039"), 3.50mm OD (0.138")
Contact Material
Brass, 65 Mn Steel · Brass, Phosphor Bronze · Brass, Copper Alloy · Brass, Bronze
