About the TE Connectivity AMP Connectors 2828 Wire To Board Headers Series

IC Source Direct is a China connector distributor, supplier and independent procurement agent for TE Connectivity AMP Connectors 2828 Wire To Board Headers Series components, matching housing, contact and mating cycles across the Shenzhen interconnect channel. The TE Connectivity AMP Connectors 2828 Wire To Board Headers Series series groups 15 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common clamp material - plating of Brass - Nickel Plated, color of Green and contact material - plating of Brass - Tin Plated. Variants differ by current, features and operating temperature, so you can match the exact current your application requires using the selection guide below. All listed TE Connectivity AMP Connectors 2828 Wire To Board Headers Series part numbers are active and orderable.

Select a variant by

Current: 10 A · 13.5 A
Features: - · Interlocking (Side)
Operating temperature: - · -40°C ~ 105°C
Pitch: 0.100\" (2.54mm) · 0.197\" (5.00mm)
Positions per level: 2 · 3 · 4 · 5 · 6 · 7 · 8
Screw material - plating: Brass - Nickel Plated · Steel, Stainless
Screw thread: M1.6 · M3
Torque - screw: 0.2 Nm (1.7 Lb-In) · 0.68 Nm (6 Lb-In)

Shared specifications

Clamp material - plating: Brass - Nickel Plated
Color: Green
Contact material - plating: Brass - Tin Plated
Housing material: Polyamide (PA66), Nylon 6/6
Mating orientation: Horizontal with Board
Mounting: Through Hole
Number of levels: 1
Package: Bulk
Wire gauge: 16-30 AWG
Wire termination: Screw - Rising Cage Clamp

Variant comparison

Parameter	282834-2	282834-3	282834-4	282834-5	282834-6	282834-7
Current	10 A	10 A	10 A	10 A	10 A	10 A
Features	-	-	-	-	-	-
Operating temperature	-40°C ~ 105°C	-40°C ~ 105°C	-40°C ~ 105°C	-40°C ~ 105°C	-40°C ~ 105°C	-40°C ~ 105°C
Pitch	0.100\" (2.54mm)	0.100\" (2.54mm)	0.100\" (2.54mm)	0.100\" (2.54mm)	0.100\" (2.54mm)	0.100\" (2.54mm)
Positions per level	2	3	4	5	6	7
Screw material - plating	Steel, Stainless	Steel, Stainless	Steel, Stainless	Steel, Stainless	Steel, Stainless	Steel, Stainless
Screw thread	M1.6	M1.6	M1.6	M1.6	M1.6	M1.6
Torque - screw	0.2 Nm (1.7 Lb-In)	0.2 Nm (1.7 Lb-In)	0.2 Nm (1.7 Lb-In)	0.2 Nm (1.7 Lb-In)	0.2 Nm (1.7 Lb-In)	0.2 Nm (1.7 Lb-In)

Request a quote on any TE Connectivity AMP Connectors 2828 Wire To Board Headers Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
