MTA-100 2.54mm IDC Header

52 variants · TE Connectivity AMP Connectors All Panel-Mount & In-Line Circular by this brand → Browse Panel-Mount & In-Line Circular category →

About the MTA-100 2.54mm IDC Header

IC Source Direct is a China connector distributor, supplier and independent procurement agent for MTA-100 2.54mm IDC Header components, matching housing, contact and mating cycles across the Shenzhen interconnect channel. The TE Connectivity AMP Connectors MTA-100 2.54mm IDC Header series groups 52 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common cable termination of IDC, connector type of Receptacle and contact finish of Gold. Variants differ by color, contact finish thickness and positions, so you can match the exact color your application requires using the selection guide below.

Select a variant by

Color
Blue · Red · White
Contact finish thickness
15.0µin (0.38µm) · 30.0µin (0.76µm)
Positions
2 · 3 · 4 · 5 · 6 · 8
Wire gauge
22 AWG · 24 AWG · 26 AWG

Shared specifications

Cable termination
IDC
Connector type
Receptacle
Contact finish
Gold
Fastening type
Locking Ramp
Features
Closed End
Mounting
Free Hanging (In-Line), Right Angle
Package
Bulk
Pitch
0.100\" (2.54mm)
Row spacing
-
Rows
1
Type
Female Socket
Wire type
Discrete or Ribbon Cable

Variant comparison

Parameter3-644020-23-644020-33-644020-63-644038-23-644038-43-644040-6
ColorWhiteWhiteWhiteRedRedBlue
Contact finish thickness30.0µin (0.76µm)30.0µin (0.76µm)30.0µin (0.76µm)15.0µin (0.38µm)15.0µin (0.38µm)15.0µin (0.38µm)
Positions236246
Wire gauge24 AWG24 AWG24 AWG22 AWG22 AWG26 AWG

Request a quote on any MTA-100 2.54mm IDC Header part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.

About TE Connectivity AMP Connectors MTA-100 2.54mm IDC Header Sourcing

What buyers ask when they search MTA-100 2.54mm IDC Header Pin Header Pitch Positions Plating.

Common questions

  • What is the MTA-100 2.54mm IDC Header used for?
  • How do I select the correct part number within the MTA-100 2.54mm IDC Header series?
  • What are the key technical specifications for the MTA-100 2.54mm IDC Header?
  • Where can I find the MTA-100 2.54mm IDC Header datasheet and order from authorized distributors?

All variants

11 products
