CUI Devices — Wire-to-Board Connectors

CUI Devices Wire-to-Board Connectors — 38 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.

Base Product Number
PJ-001 · PJ-017 · PJ-028 · PJ-031
Actual Diameter
0.051" (1.30mm ID), 0.150" (3.80mm OD) · 0.051" (1.30mm ID), 0.165" (4.20mm OD) · 0.031" (0.80mm ID), 0.132" (3.35mm OD) · 0.039" (1.00mm ID), 0.157" (4.00mm OD)
Industry Recognized Mating Diameter
1.30mm ID (0.051"), 3.50mm OD (0.138") · 1.35mm ID (0.053"), 3.50mm OD (0.138") · 0.90mm ID (0.035"), 3.20mm OD (0.126") · 1.00mm ID (0.039"), 3.50mm OD (0.138")
Positions Per Level
5 · 3 · 7 · 2
Mating Length/Depth
0.335" (8.50mm) · 0.276" (7.00mm) · 0.360" (9.15mm) · 0.303" (7.70mm)
Wire Gauge
14-22 AWG · 12-22 AWG · 14-26 AWG · 12-24 AWG
Current Rating (Amps)
3.5 A · 2 A · 4 A · 2.5 A
Housing Material
Polyamide (PA10T), Nylon 10T · Polybutylene Terephthalate (PBT) · Polyamide (PA9T), Nylon 9T · Polyvinyl Chloride (PVC)
