TE Connectivity AMP Connectors — PCB Single-Post Pins

TE Connectivity AMP Connectors PCB Single-Post Pins — 13 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source

title
1-928776-4 · 1-928776-6 · 350491-1 · 3-60803-1
Base Product Number
928776 · 350491 · 60803 · 87623
Length - Overall
0.520" (13.21mm) · 0.661" (16.80mm) · 0.405" (10.29mm) · 0.375" (9.53mm)
Mounting Hole Diameter
0.035" (0.89mm) · 0.067" ~ 0.073" (1.70mm ~ 1.85mm) · 0.046" ~ 0.050" (1.17mm ~ 1.27mm) · 0.036" (0.91mm)
Contact Finish Thickness
31.5µin (0.80µm) · 98.4µin (2.50µm) · 30.0µin (0.76µm) · 39.4µin (1.00µm)
Board Thickness
0.063" (1.60mm) · 0.062" (1.57mm) · 0.062" ~ 0.093" (1.57mm ~ 2.36mm)
Package
Bulk · Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
Pin Size - Above Flange
0.025" (0.64mm) Square · 0.093" (2.36mm) Dia · 0.058" (1.47mm) Dia
