5103309-3
TE Connectivity AMP Connectors
16AMP-LatchTube
Ref. price$2.8700
Lead time on requestGet quote ›
TE Connectivity AMP Connectors 5103 Series
145 variants · TE Connectivity AMP Connectors
About the TE Connectivity AMP Connectors 5103 Series
The TE Connectivity AMP Connectors 5103 Series series groups 145 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common applications of -, connector type of Header and contact finish - post of Tin. Variants differ by contact finish - mating, contact finish thickness - mating and contact length - mating, so you can match the exact contact finish - mating your application requires using the selection guide below.
Select a variant by
- Contact finish - mating
- Gold · Tin
- Contact finish thickness - mating
- 30.0µin (0.76µm) · 100.0µin (2.54µm)
- Contact length - mating
- 0.240\" (6.10mm) · 0.318\" (8.08mm)
- Contact length - post
- 0.130\" (3.30mm) · 0.135\" (3.43mm)
- Contact material
- Brass · Phosphor Bronze
- Fastening type
- Detent Lock · Push-Pull
- Insulation height
- 0.400\" (10.16mm) · 0.549\" (13.94mm)
- Mounting type
- Through Hole · Through Hole, Right Angle
Shared specifications
- Applications
- -
- Connector type
- Header
- Contact finish - post
- Tin
- Contact finish thickness - post
- 100.0µin (2.54µm)
- Contact shape
- Square
- Current rating
- 3A
- Features
- -
- Gender
- Male Pin
- Ingress protection
- -
- Insulation color
- Black
- Insulation material
- Thermoplastic
- Mated stacking heights
- -
Variant comparison
| Parameter | 5-103080-2 | 5-103080-3 | 5-103080-5 | 5-103080-6 | 5-103080-8 | 5-103166-1 |
|---|---|---|---|---|---|---|
| Contact finish - mating | Tin | Tin | Tin | Tin | Tin | Gold |
| Contact finish thickness - mating | 100.0µin (2.54µm) | 100.0µin (2.54µm) | 100.0µin (2.54µm) | 100.0µin (2.54µm) | 100.0µin (2.54µm) | 30.0µin (0.76µm) |
| Contact length - mating | 0.240\" (6.10mm) | 0.240\" (6.10mm) | 0.240\" (6.10mm) | 0.240\" (6.10mm) | 0.240\" (6.10mm) | 0.318\" (8.08mm) |
| Contact length - post | 0.130\" (3.30mm) | 0.130\" (3.30mm) | 0.130\" (3.30mm) | 0.130\" (3.30mm) | 0.130\" (3.30mm) | 0.135\" (3.43mm) |
| Contact material | Brass | Brass | Brass | Brass | Brass | Phosphor Bronze |
| Fastening type | Push-Pull | Push-Pull | Push-Pull | Push-Pull | Push-Pull | Detent Lock |
| Insulation height | 0.549\" (13.94mm) | 0.549\" (13.94mm) | 0.549\" (13.94mm) | 0.549\" (13.94mm) | 0.549\" (13.94mm) | 0.400\" (10.16mm) |
| Mounting type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole, Right Angle |
Request a quote on any TE Connectivity AMP Connectors 5103 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the TE Connectivity AMP Connectors 5103 Series variants differ?
- TE Connectivity AMP Connectors 5103 Series part numbers differ by contact finish - mating, contact finish thickness - mating, contact length - mating and contact length - post. Use the selection guide above to pick by contact finish - mating.
- How many TE Connectivity AMP Connectors 5103 Series part numbers are listed?
- 145 TE Connectivity AMP Connectors 5103 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for TE Connectivity AMP Connectors 5103 Series?
- Request a quote (RFQ) for any TE Connectivity AMP Connectors 5103 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
