Molex — Mezzanine & Stacking Connectors

Molex Mezzanine & Stacking Connectors — 49 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.

title
0465562745 · 0513380774 · 0513380874 · 0513380974
Height Above Board
0.421" (10.70mm) · 0.053" (1.35mm) · 0.140" (3.55mm) · 0.165" (4.20mm)
Base Product Number
046556 · 051338 · 052465 · 052885
Number of Positions
80 · 70 · 90 · 26
Mated Stacking Heights
12mm, 13mm, 13.5mm, 14.5mm, 15mm · 1.5mm · 4.5mm, 5.65mm, 7mm · 6mm, 7mm, 8mm, 9mm, 10mm
Contact Finish Thickness
30.0µin (0.76µm) · 8.00µin (0.203µm) · 39.4µin (1.00µm) · 10.0µin (0.25µm)
Connector Type
High Density Array, Male · Receptacle, Center Strip Contacts · Header, Outer Shroud Contacts · Plug, Outer Shroud Contacts
Package
Tape & Reel (TR) Cut Tape (CT) · Tube · Tray · Box
