Molex — Pin Headers

Molex Pin Headers — 193 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.

title
0009652028 · 0010081021 · 0010081031 · 0010897041
Number of Positions
2 · 3 · 4 · 6
Base Product Number
000965 · 001008 · 001089 · 001524
Contact Length - Post
0.142" (3.60mm) · 0.155" (3.94mm) · 0.107" (2.71mm) · 0.130" (3.30mm)
Insulation Height
0.482" (12.25mm) · 0.125" (3.18mm) · 0.090" (2.29mm) · 0.591" (15.00mm)
Contact Length - Mating
0.419" (10.65mm) · 0.470" (11.94mm) · 0.240" (6.10mm) · 0.295" (7.49mm)
Overall Contact Length
0.687" (17.45mm) · 0.750" (19.05mm) · 0.437" (11.10mm) · 0.560" (14.22mm)
Contact Finish Thickness - Mating
200.0µin (5.08µm) · 100.0µin (2.54µm) · 150.0µin (3.81µm) · 15.0µin (0.38µm)
