Bulgin — Power Entry Modules

Bulgin Power Entry Modules — 22 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.

title
BVA01/Z0000/01 · BVB01/Z0000/01 · BZM27/Z0000/53B · PF0001/28
Base Product Number
BVA01/Z · BVB01/Z · BZM27/Z · PF0001
Panel Cutout Dimensions
Rectangular - 33.00mm x 53.20mm · Rectangular - 45.90mm x 21.30mm · Rectangular - 27.30mm x 31.12mm · Rectangular - 28.10mm x 31.30mm
Connector Style
IEC 320-C14 · IEC 320-C13 · IEC 320-C16 · IEC 320-C20
Panel Thickness
0.059" (1.50mm) · 0.039" (1.00mm) · 0.118" (3.00mm) · 0.157" (4.00mm)
Approval Agency
CSA, ENEC, UL, VDE · CSA, UL · CCC, CSA, ENEC, UL, VDE · CSA, RCM, UL
Mounting Type
Panel Mount, Flange · Panel Mount, Snap-In · Panel Mount, Snap-In; Through Hole, Right Angle · Panel Mount, Flange; Through Hole, Right Angle
Connector Type
Receptacle, Male Blades - Module · Receptacle, Male Blades · Plug, Female Sockets · Receptacle, Female Sockets
